This item has now been allocated and so is no longer available.

GEE Mk II receiver.


The Mk II receiver was introduced in March 1943 and had four removable RF untis which could be change in flight to extend the set's
frequency range.
Two of the units had pre-tuned spot frequencies, whilst the other two had tuning dials.

This example is fitted with a tuneable RF unit and dates from late WWII.

Sec/Ref: 10DB/847

GEE<br>Receiver (GEE MkII)

GEE Receiver (GEE MkII) (Photograph Number 0158)
