Receiver Type R1273.

This receiver was used in direction finding stations. There were four separate vertical aerials connected into the
goniometer on the left and also a vertical sense aerial was suspended from the intersection of two catenary lines that were
attached to opposite pairs of the vertical aerials.

Sec/Ref: 10D/553

Receiver Type R1273 (Photograph Number 0201)

Click on the image to get the full size image.
