Receiver Type R1475

This consists of the Receiver Type 88 and the Power Unit Type 360.
The receiver is a general-purpose Ground Station equipment, nominally covering the frequency range from 2 to 20Mc/s, in four ranges.
There is a Guard receiver fitted at right centre. The guard channel unit was crystal controlled, and usually set on an HF distress frequency.
Receiver<br>Type R1475(working)

Receiver Type R1475(working) (Photograph Number 0075)
