Signal Generator No.1.

These units were installed in Post Office Telex exchanges to provide the test signal, "The quick Brown fox
jumps over the lazy dog." to enable the receiving margins to be checked by a sequence of messages having
pre-determined distortion on the signal.
Signal Generator<br>No1

Signal Generator No1 (Photograph Number 0008)

Click on the image to get the full size image.
