Transmitter Type T1540

This unit is a low power single channel ground station transmitter designed for speech modulated VHF transmissions
in the range 100Mc/s to 156Mc/s. It has an inbuilt AC mains power supply and the transmitter unit is a modified version of
the BC625-SCR522 producing an output power of approximately 5 watts. This unit is serial No. 1260.

Sec/Ref: 10D/2120

Transmitter<br>Type T1540

Transmitter Type T1540 (Photograph Number 0182)
